Product Description
E9 48V 15A Lithium Battery Charger – Smart & Universal
Compatible with LiFePO₄, Lead Acid, and Li-ion | 100-240Vac input | Full protections: over-voltage, over-current, short circuit, thermal
| Model | E9 – 48V 15A Lithium Battery Charger | |
| Input Voltage | 100-240Vac (universal, 50/60Hz) | |
| Rated Output | 48V / 15A (max 900W @220Vac) | |
| Casing Material | Aluminum die-casting – IP65 waterproof rating | |
| Protections | Input under/over-voltage, overheat, output overcurrent, output overvoltage, short circuit protection | |
| Cooling | Natural convection + aluminum housing | |
| Rated Voltage | Lead Acid (Absorption) | LiFePO₄ (Bulk) | Lithium-ion (Li-ion) | Charge Current @220Vac |
|---|---|---|---|---|
| 12V | 14.7V | 14.6V | 16.8V | 30A |
| 24V | 29.4V | 29.2V | 29.4V | 30A |
| 36V | 44.1V | 43.8V | 42V | 30A |
| 48V | 58.8V | 58.4V | 58.8V | 25A / 15A (E9 model) |
| 60V | 73.5V | 73V | 67.2V | 20A |
| 72V | 88.2V | 87.6V | 84V | 15A |
| 84V | 102.9V | 102.2V | 100.8V | 12A |
| 96V | 117.6V | 116.8V | 117.6V | 10A |
AC cable length and wire diameter are optional. If no special requirements, they will be matched with appropriate specifications according to the model.
DC cable length and wire diameter are optional. Customers can also provide their own DC plug (as long as it is commercially available).
✔️ Use only with compatible battery types (Lead Acid, LiFePO₄, Li-ion). Never exceed rated voltage.
✔️ Ensure proper ventilation – do not cover the charger during operation.
✔️ IP65 rated for outdoor use, but avoid submersion.
✔️ Disconnect from mains before connecting/disconnecting battery.
✔️ If the charger behaves abnormally (overheating, smoke), disconnect immediately.
