5120 Series LiFePO₄ Battery | 5.12kWh Deep Cycle Lithium Battery with Bluetooth
The Elite-5120 Series represents the pinnacle of lithium energy storage, offering three versatile configurations—12.8V 400Ah (Elite-5120A), 25.6V 200Ah (Elite-5120B), and 51.2V 100Ah (Elite-5120C)—all delivering 5.12kWh of usable energy. Built with premium LiFePO₄ (lithium iron phosphate) technology, these batteries provide >6000 cycles, 15‑year design life, and integrated Bluetooth monitoring. Certified to UL1973, IEC62619, and CE standards, the Elite‑5120 series is the ultimate power solution for solar storage, RVs, golf carts, marine applications, and backup power systems.
📊 Basic Specifications – Model Comparison
| Parameter | Elite-5120A | Elite-5120B | Elite-5120C |
|---|---|---|---|
| Rated Voltage | 12.8V | 25.6V | 51.2V |
| Rated Capacity | 400Ah | 200Ah | 100Ah |
| Rated Energy | 5,120Wh (5.12kWh) | ||
⚡ Operation Parameters (All Models)
| Parameter | Value |
|---|---|
| Voltage Range | 10V – 14V (per 12V module) |
| Cut-off Voltage | 10V (per 12V module) |
| Recommended Charge Current | ≤ 120A |
| Max Constant Charge Current | 200A |
| Max Constant Discharge Current (Model Specific) | Elite-5120A: 250A (constant), 350A pulse (30s) Elite-5120B: 150A (constant), 200A pulse (30s) Elite-5120C: 100A (constant), 150A pulse (30s) |
📏 Physical Parameters (All Models)
| Parameter | Value |
|---|---|
| Dimensions (W × D × H) | 460 × 320 × 247 mm 18.11 × 12.60 × 9.72 in |
| Weight | 43 kg (95 lb) |
| Display Method | Bluetooth (real‑time monitoring via smartphone app) |
🔄 Service Life & Reliability
| Parameter | Value |
|---|---|
| Cycle Life | >6000 cycles (0.5C @ 25°C, 80% DOD) |
| Design Life | 15 years |
🌡️ Environment & Operating Conditions
| Parameter | Value |
|---|---|
| Humidity | 5% – 95% RH (non‑condensing) |
| Charge Temperature Range | -20°C to 45°C / -4°F to 113°F Heating function for low‑temperature charging |
| Discharge Temperature Range | -20°C to 55°C / -4°F to 131°F |
| Storage Temperature Range | -20°C to 45°C / -4°F to 113°F |
✅ Certifications & Safety
| Parameter | Value |
|---|---|
| Safety & Certification | CE, UL1973, IEC62619 |
| Transportation | UN38.3 (safe for air, sea, and ground transport) |
✨ Key Features & Benefits
🔋 Three Voltage Options, Same Energy
Choose the ideal voltage for your system—12.8V, 25.6V, or 51.2V—all delivering 5.12kWh of reliable power. Perfect for series or parallel configurations.
📱 Bluetooth Monitoring
Monitor real‑time voltage, current, capacity, temperature, and cycle count directly from your smartphone. No external meter required.
⚡ High Power Output
Elite-5120A supports 250A continuous, 350A pulse – ideal for heavy‑duty inverters, motors, and high‑demand applications.
❄️ Low‑Temperature Charging
Built‑in heating function enables safe charging even at -20°C, ensuring reliable operation in cold climates.
🛡️ Industry-Leading Certifications
Certified to UL1973 and IEC62619 – the highest safety standards for stationary and motive power applications.
🌍 Eco‑Friendly & Maintenance‑Free
No toxic heavy metals, no acid spills, zero maintenance. 100% recyclable and compliant with global environmental standards.
🔧 Applications
☀️ Solar Energy Storage
Ideal for residential and commercial solar systems – store excess energy for night use or grid outages.
🚐 RV & Camper Van Power
Lightweight, high‑capacity power for off‑grid adventures. Runs air conditioners, refrigerators, and electronics.
🏌️ Golf Carts & Utility Vehicles
Drop‑in replacement for lead‑acid batteries – longer range, faster charging, and zero maintenance.
🔌 Backup & UPS Systems
Reliable backup power for homes, medical equipment, telecommunications, and industrial systems.
⚓ Marine & Boat Power
Safe, sealed, and vibration‑resistant – perfect for trolling motors, fish finders, and onboard electronics.
🏭 Off‑Grid & Telecom
Trusted by remote telecom towers, monitoring stations, and off‑grid cabins for dependable 24/7 power.
• 1 × Elite-5120 Series LiFePO₄ battery (model as ordered)
• Bluetooth monitoring module (built‑in)
• Battery terminals (M8 bolts + washers)
• User manual with BMS configuration guide
Charger sold separately (recommended 30A–200A LiFePO₄ charger based on model)
We offer OEM/ODM services – custom voltages, capacities, connectors, and enclosures. Contact our engineering team for technical specifications, bulk pricing, and sample requests.
